Installing Additional Components
PCI Card Installation
Chapter 3
34
Step 2. Remove the cover from the PCI card cage.
CAUTION Observe all ESD safety precautions while performing this procedure. Failure to
follow ESD safety precautions could result in damage to the server.
Step 3. If a blank panel is installed at the end of the card cage (for the card position/socket which will be
used), remove the blank panel.
Step 4. Grasp the card to be installed by opposing edges and orient the card such that its connector is
aligned with the card cage socket and the PCI interface connector can be extended through the
opening at the end of the card cage. Insert the card into the desired socket.
Step 5. Secure the card in the card cage using the retaining screw provided.
Step 6. Connect any cables (if appropriate) to card sockets at this time.
Installing the PCI Card Cage Assembly
To install the PCI card cage assembly, perform the following steps:
WARNING Ensure that the system is powered down and all power sources have been
disconnected from the server prior to removing or replacing the PCI card cage
assembly.
Voltages and hazardous energy can be present at various locations within the server
whenever a power source is connected. This hazard is present even when the power
switch is in the off position.
Failure to observe this warning could result in personal injury or damage to
equipment.
CAUTION Observe all ESD safety precautions while performing this procedure. Failure to follow ESD
safety precautions could result in damage to the server.
Step 1. If the card cage cover has been removed, insert the cover tabs (fan end of cover) into the
corresponding slots on the card cage and press the cover into position on the card cage. Slide the
cover toward the front of the card cage to secure the cover in place.
Step 2. Orient the PCI card cage as shown in Figure 3-13. Lift the release lever and hold it in the open
position. Lower the card cage into position and press gently to seat card cage connectors.
