Troubleshooting
HP NonStop S-Series Hardware Installation and FastPath Guide—541880-001
D-40
Restoring Software on the Hard Disk
14. Click I accept this agreement. Click
Next.
The Installing Devices screen appears.
15. In the Regional Settings screen,
customize the appearance of numbers,
currencies, dates, and keyboard layout.
Click Next.
The Name and Organization screen
appears.
16. For name, type NonStop S-series
System Console.
Type the name of your organization.
Click Next.
The Date and Time Settings screen
appears.
17. Set the date and time.
Check Automatically adjust clock for
daylight saving changes. Click Next.
Installing Components screens appear.
Performing Final Tasks screens appear.
18. When setup is complete, click Finish.
Click Restart Now.
The system restarts.
More software is installed.
19. Press Enter. The system automatically converts the file
system from FAT to NTFS.
The Desktop appears.
20. Double-click Connect to the Internet. The Internet Connection wizard appears.
21. Select I want to setup my internet
connection manually....
The Setup Internet Connection screen
appears.
22. Select I connect through a local area
network (LAN). Click Next.
The Local Area Network Configuration
screen appears.
23. Select Automatic Discovery of proxy
server (recommended). Click Next.
The Setup Internet Mail Account appears.
24. Select No. Click Next. The Completing Internet Connection wizard
appears.
25. Clear the checkmark.
Click Finish.
The Desktop appears.
The Connect to Internet icon disappears.
26. Start > Settings > Control Panel The Control Panel appears.
27. Double-click the System icon. The System Properties screen appears.
28. In the Network Identification tab, start
the Network Identification Wizard.
The Network Identification Wizard appears.
29. Click the Network ID button. Click Next.
30. Select This computer is part of a
business network. Click Next.
The Connecting to the Network screen
appears.
31. Select My computer uses a network
without a domain. Click Next.
The Workgroup dialog box appears.
Table D-8. Install Windows XP Professional Operating System (page 2 of 4)
Action Result
