Display 21 – Constant voltage charging display
************** ##############
* aaaa bbbb * #MTDif MPDif #
* cccc dddd * #BupV BDownV#
* eeee ffff * #AverV SumMF #
* * # #
************** ##############
aaaa Difference between measured voltage and goal voltage, decimal point is not
shown.
bbbb Difference between measured voltage and result of previous measurement
(basically same as using change of error), decimal point is not shown.
ccc Battery up voltage (highest measured voltage), maximum ripple voltage.
ddd Battery down voltage (lowest measured voltage), minimum ripple voltage.
eee Average measured voltage.
fff Sum of membership function sets beliefs, range 0.00-9.99, decimal point is
not shown; e.g. 1.53 is shown as 153. If sum of 1.00 is reached then battery
full indication is shown.
Display 22 – Battery full detection
************** ##############
* Eaaa Cbbb * #DeriC ChAm #
* Dccc Rddd * # VDif VDrop #
* Ieee Afff * # VDTi AvDif #
* Tggg hhhh * # Temp Volt #
************** ##############
Letters E, C, D, R, I, A, T and V are displayed if values are shorter than 4 digits.
Eaaa DerivCount membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Cbbb ChargeAmount membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Dccc VolDiffToMax membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Rddd VolDropCnt membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Ieee VolDiffTime membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Afff AverDiff membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Tggg Temperature membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
Vhhh Voltage membership function set, range 0.00-1.00, decimal point is not
shown; e.g. 0.23 is shown as 023.
