To Operate Your Doppler Flow Meter for the First Time:
1. Complete all the steps in “Before Installing the Unit” on page 2-1.
2. Complete all the steps in “Installation Procedures” on page 2-9.
3. Turn on power and observe the display panel LCD. The display will show the
model name and number of the unit.
4. Following the prompts presented by the display panel LCD, and making your
entries using the keypad, configure your unit for operation.
4
The LCD screen displays SELECT RATE. Select the unit of measure for rate
display:
If you select FPS, the flow meter will automatically begin measuring flow in feet
per second. If you select keys 2 through 7, the LCD screen will ask that you enter
your pipe ID in inches. See “Standard Pipe Data” on page 4-9 to estimate your
pipe ID.
After you enter your pipe ID, the LCD screen will then display SELECT
TOTALIZER. Select the unit of measure for totalizer display:
Attention:
If your display flashes LOW BAT at any time during setup or
programming, consult “Status of Unit Power” on page 3-2 for
troubleshooting information.
Note: If you are switching from battery (DC) power to AC power and the
A/C Select switch selection does not match your incoming power level,
you may see a LOW BAT warning in the front panel display. Adjust the
A/C Select switch to the correct incoming power level (115 VAC or
230 VAC), and this warning should disappear.
Table 2-4. Rate selection
Key Selection Definition
1 FPS Feet per second
2 GPM Gallons per minute
3 CFS Cubic feet per second
4 MGD Million gallons per day
5 MPS Meters per second
6 LPS Liters per second
7 CMS Cubic meters per second
8 < = > Use this key to move between rate screens
