4-12 Specifications and Reference Information 5707070-A
Sono-Trak™ Doppler Ultrasonic Flow Meter
Velocity Conversion Tables
Table 4-7. Velocity conversion table (MPS to LPM and LPS)
Nominal pipe
size (mm)
MPS
0.3
MPS
0.6
MPS
1.0
MPS
1.5
MPS
2.0
MPS
2.5
MPS
3.0
MPS
5.0
MPS
7.0
(10 mm wall) LPM LPM LPM LPM LPM LPM LPS LPS LPS
50 35 71 118 177 236 294 5.9 10 14
75 80 159 265 398 530 663 13.3 22 31
100 141 283 471 707 942 1178 23.6 39 55
150 318 636 1060 1590 2120 2651 53 88 124
200 565 1130 1885 2827 3770 4712 94 157 220
250 884 1768 2945 4418 5890 7363 147 245 344
300 1272 2544 4241 6361 8482 10602 212 353 495
400 2262 4524 7539 11309 15078 18848 377 628 880
Table 4-8. Velocity conversion table (MPS to LPS and M
3
/Hr)
Nominal pipe
size (mm)
MPS
0.3
MPS
0.6
MPS
1.0
MPS
1.5
MPS
2.0
MPS
2.5
MPS
3.0
MPS
5.0
MPS
7.0
(15 mm wall) LPS LPS LPS LPS LPS LPS M
3
/Hr M
3
/Hr M
3
/Hr
500 59 88 196 295 392 491 35.3 58.9 82.5
600 85 170 283 424 566 707 51 85 119
750 133 266 442 663 884 1104 79.5 132.5 186
1000 236 472 785 1178 1570 1963 141.4 236 330
1200 339 678 1131 1696 2262 2827 204 339 475
1500 530 1060 1767 2651 3534 4418 318 530
