FLASH SIGNALSUSING THE BUILT-IN FLASH
34 35
Grip both sides of the flash
and gently lift it. The flash will
fire every time when it is up.
Push the flash down to turn it
off.
The built-in flash provides coverage for lens focal lengths from
24mm to 80mm. The flash output is automatically controlled by
the camera's TTL flash metering system.
• The flash is fully charged when appears in the viewfinder.
• The flash has a limited range that is dependent on the aperture and film
speed. See page 36.
Customized Function #5 - Flash Control in P-Mode
The default setting is Manual Switchover; the flash will fire every
time the shutter-release button is pressed when the flash is up.
Autoswitchover is available though the customize settings; the
flash will fire only when necessary when it is up and P-mode is
set. See page102.
The following indicators will appear in the viewfinder to report the
status of the flash.
Flash is charged and ready.
(Blinks after a photograph is taken.) Flash
output was sufficient to provide correct
exposure.
High-speed Sync Flash is ready (p 87).
Only available with the 5400HS flash unit
(sold separately).
Wireless/Remote Flash is selected (p 92).
Use of flash is recommended. This symbol
only blinks when Autoswitchover is
selected in Customized Function #5, the
camera is in P mode, the subject is backlit,
and the built-in flash is down.
