Getting To Know Your Phone 17
Getting To Know Your Phone
Phone Views
The following diagrams illustrate the front, back, and
bottom views of your phone.
1 Earpiece
2 Side volume keys
3 Display
4 Left softkey
5 Joystick
(4-way navigation
with center push key)
6 Options key
7 Keypad
8 Power On/Off key
9 Clear key
10 Right softkey
2
3
5
6
7
8
9
10
4
1
11 External antenna connector
12 Headset jack
(2.5mm plug/audio jack)
13 Back cover latch
14 Accessory Connector
(Handsfree, Charger, FM
radio, MP3, Chatboard, etc.)
15 Microphone
16 Charging connector
13
11
12
14
16
15
