4.5.4 UTILITY
Push the UTILITY button to display the Utility Menu as follows.
Options Comments
Sys Info (F1)
(menu page 1)
Display the software and hardware versions, serial number and other information
about the oscilloscope.
Update (F2)
(menu page 1)
Insert a USB disk with an upgrade program; the disk icon at the top left corner is
highlighted. Press F4 to Confirm the Update Program button; the Software Upgrade
dialog will pop up. Press F2 (Highlighted Update) to cancel operation.
Self Cal* (F3)
(menu page 1)
Press this option and the Self Calibration dialog will pop up. Press F4 to Confirm and
perform the self calibration. Press F3 (Highlighted Self Cal) to cancel. Remove all
probes before test.
System (F2)
(menu page 2)
Set System parameters. Sound (On/Off), Language (English, Chinese), Interface
color, Time Set (Date and Time), PC Set (USB or NET
*
).
Shutdown (F3)
(menu page 2)
Set the meters Auto-Off timing when Action is set to PowerOff. Set Auto-Off time (F2)
using the Multifunction control arrow keys. Press F3 to confirm setting changes,
Press F4 to cancel changes, Press F5 to go back to main Utility menu.
Video (F4)
(menu page 2)
Record a video of your waveforms.
Play
USB to SD
SD to USB
Delete
Back – go back to the main Utility menu
Probe Ck (F2)
(menu page 3)
Probe Check
Probe - (CH-1x, CH2-1x, CH1-10x, CH2-10x) Set to match probe setting.
Check - Turn on 1KHz Comp signal
Finish - Turn off Comp signal
Cancel - Cancel Probe Check
*
Ethernet port reserved for future use
