- 11 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
ͽͶ͑ͺΟΥΖΣΟΒΝ͑ΆΤΖ͑ΟΝΪ
XWVXZZ
2.2 Technical Specification
Item Description Specification
1 Frequency Band
GSM850 EGSM
TX: 824 ~ 849 MHz TX: 880 ~ 915MHz
RX: 869 ~ 894 MHz RX: 925 ~ 960 MHz
DCS
TX: 1710 ~ 1785 MHz
RX: 1805 ~ 1880 MHz
PCS
TX: 1850 ~ 1910 MHz
RX: 1930 ~ 1990 MHz
2 Phase Error
RMS < 5 degrees
Peak < 20 degrees
3 Frequency Error < 0.1 ppm
4 Power Level
Level Power Toler. Level Power Toler.
6 31dBm ·3dB 14 15dBm · 3dB
7 29dBm ·3dB 15 13dBm · 3dB
8 27dBm ·3dB 16 11dBm · 5dB
9 25dBm ·3dB 17 9dBm · 5dB
10 23dBm ·3dB 18 7dBm · 5dB
11 21dBm ·3dB 19 6dBm · 5dB
12 19dBm ·3dB
GSM850/EGSM
5 33dBm ·2dB 13 17dBm · 3dB
Level Power Toler. Level Power Toler.
1 28dBm ·3dB 9 12dBm · 4dB
2 26dBm ·3dB 10 10dBm · 4dB
3 24dBm ·3dB 11 8dBm · 4dB
4 22dBm ·3dB 12 6dBm · 4dB
5 20dBm ·3dB 13 4dBm · 4dB
6 18dBm ·3dB 14 2dBm · 5dB
7 16dBm ·3dB 15 0dBm · 5dB
DCS/PCS
0 30dBm ·2dB 8 14dBm · 3dB
2. SYSTEM SPECIFICATION
