3. Select Back until you return to the main menu.
Tip: You can also use manual login to the net
call service. Use the same settings instructions
as with automatic login, but ensure that
Registration is set to When needed and
Transport type is set to UDP or TCP. With
manual login, you need to manually select the
network used in the net call service.
Connect to the net call service
To make or receive a net call, your device must be
connected to a net call service. Select Menu > Connect. >
Internet tel..
If you have selected automatic login, your device
connects to the net call service automatically. If you
have selected to login to the service manually, choose
an available connection network from the list and press
Select to connect to the net call service. The saved
networks, which are marked with a star icon, are shown
first on the list. If you want to stop the connection from
establishing, select Cancel.
Select Options and from the following:
• Connect to service — to establish a connection to a
service, when there is a net call service and suitable
connection network available.
• Disconnect from serv. — to end the connection to
the net call service.
• Change service — to choose the net call service for
outgoing calls, if the device is connected to more
than one service. This option is shown only if there
is more than one configured service available.
• Configure service — to configure new services. This
option is shown only if there are services that have
not been configured.
• Save network — to save the network you are
currently connected to. The previously saved
networks are marked with a star icon on the list of
connection networks. This option is shown only if
you are connected to an unsaved wireless LAN
network.
• Use hidden network — to connect to a net call
service using a hidden wireless LAN network.
• Refresh — to manually refresh the list of connection
networks. Use this option, if your wireless LAN
network is not shown on the list. The list is also
refreshed automatically every 15 seconds.
The available options may vary.
Your device can be connected only to one wireless LAN
access point at a time. If you use two or more net call
services, which use the same access point, your device
may be connected to multiple services at the same time.
The service used for outgoing net calls is shown in the
view, where the connection networks are listed, and
can be changed by selecting Change service.
After you have successfully connected to a service, you
can save the used wireless LAN network as a known
access point.
Connect using a shortcut
You may have a shortcut for Internet tel. in the active
standby or you can add a shortcut if it is not available.
See "Standby mode settings," p. 95. By using the
shortcut, you can register manually, if a net call service
51
Make calls
