*HWWLQJ6WDUWHG
&KDUJLQJ<RXU%DWWHU\
<RXU&KDUJHU
Your phone was packaged with either a
rapid or travel charger. It is important that
you fully charge your battery before you
use your phone. Both chargers supply
power to charge your battery while the
battery is attached to your phone. If your
phone is On, it can receive calls while using
either charger.
Note! NEVER attach the charger to a phone
that does not have a battery installed.
1 If you have a rapid charger, plug the
charger into a standard wall electrical
outlet. If you have a travel charger, connect the appropriate AC
power cord and phone charging cord to the travel charger.
2 Hold the phone with the display and keypad facing up.
3 Hold the small plug on the charger cord so the lightning bolt
symbol ( ) is up.
4 Align the small plug on the charger cord with the connector on
the bottom of your phone. The connector on the phone is above
the lightning bolt symbol ( ).
5 Press the plug into the connector until the plug “snaps” into place.
The icon is alternated with the icon when the phone is
powered on and the phone is charging.
Note! Do not twist while inserting or removing the small plug on the
charger cord!
6 Continue charging the phone until the battery is fully charged.
7 To disconnect the charger, lift the plug connected to the phone
upwards and pull it out.
&KDUJH2QO\0RGH
If your phone is off, attaching the charger will cause the phone to
activate in charge-only mode. When this mode is activated, the
message Charging Only appears in the display. Your phone is
now fast (rapid) charging the battery. When your phone is fully
charged, Battery Charged appears in the display.
Note! You cannot make or receive calls when your phone is in charge-
only mode.
rapid
travel
UDSLG
WUDYHO
