WLAN network name — Select Enter manually or Search for networks. If you
select an existing network, the WLAN network mode and WLAN security mode are
determined by the settings of its access point device.
Network status — Define whether the network name is displayed.
WLAN network mode — Select Ad-hoc to create an ad hoc network and to allow
devices to send and receive data directly; a WLAN access point device is not needed.
In an ad hoc network, all devices must use the same WLAN network name.
WLAN security mode — Select the encryption used: WEP, 802.1x, orWPA/WPA2
(802.1x and WPA/WPA2 are not available for ad hoc networks). If you select Open
network, no encryption is used. The WEP, 802.1x and WPA functions can be used
only if the network supports them.
Homepage — Enter the web address of the starting page.
Use access point — Set the device to create a connection using this access point
automatically or after confirmation.
The available options may vary.
Security settings for WEP
Define the WEP security settings if you have selected the wired equivalent privacy
(WEP) as the WLAN security mode.
1 Select Menu > Settings and Connectivity > Destinations.
2 Select the access point group that has the desired WLAN access point, and select
the access point.
You can also define WEP settings when creating a new WLAN access point.
3 Select WLAN security mode > WEP.
4 Select WLAN security settings, and define the following:
WEP key in use — Select the wired equivalent privacy (WEP) key number. You
can create up to four WEP keys. The same settings must be entered on the WLAN
access point device.
124 Connectivity
