Connecting to Networks and Devices
Sending Data via Bluetooth
1. Open the appropriate application and select the file
or item you want to share.
2. Select the option for sharing via Bluetooth. The
method may vary by application and data type.
3. Tap a Bluetooth device the phone has paired with or
wait for it to search for new devices and tap one of
them.
Receiving Data via Bluetooth
1. Turn Bluetooth on before trying to receive data via
Bluetooth.
NOTE: If the phone has not been paired with the
sending device, you may need to tap Bluetooth >
Z797C in Settings to keep the phone detectable
through Bluetooth.
2. Flick down the Status Bar and tap .
3. Tap Accept to start receiving the data.
Depending on your storage setting and whether a
microSDXC card is installed, received files are stored
automatically in a dedicated folder (Bluetooth, for
instance) in the phone storage or microSDXC directory.
You can access them with the File Manager app.
Received contacts (vCard files) are automatically
imported to your contact list.
Pairing With Another Bluetooth
Device
1. Press the Home Key > Menu Key > System
settings > Bluetooth.
2. Slide the Bluetooth switch to the ON position if
Bluetooth is off.
Your phone automatically scans for and displays the
IDs of all available Bluetooth devices in range. Tap
SEARCH FOR DEVICES if you want to scan again.
3. Tap the device you want to pair with.
4. If necessary, confirm that the Bluetooth passkeys are
the same between the two devices and tap Pair.
Alternately, enter a Bluetooth passkey and tap Pair.
Pairing is successfully completed when the other
device accepts the connection or the same passkey
is entered.
NOTE: The Bluetooth passkey may be fixed for certain
devices, such as headsets and hands-free car kits. You
can try entering 0000 or 1234 (the most common
passkeys) or refer to the documents for that device.
Connecting to Networks and Devices
Disconnecting Your Phone From
the Computer
To disconnect the phone from the computer, simply
unplug the USB cable when you’re finished.
Removing the microSDXC Card
From Your Phone
If you need to remove the microSDXC card while the
phone is on, you should unmount it first.
1. Press the Home Key > Menu Key > System
settings > Storage.
2. Scroll down and tap Unmount SD card > OK.
3. When Unmount SD card changes to Mount SD
card you can safely remove the microSDXC card
from the phone.
Erasing the microSDXC Card
1. Press the Home Key > Menu Key > System
settings > Storage.
2. Scroll down and tap Erase external SD card >
Erase SD card > Erase everything.
CAUTION! The formatting procedure erases all
the data on the microSDXC card, after which the files
CANNOT be retrieved.
Connecting to Your
Computer via USB
You can connect your phone to a computer with a USB
cable and transfer music, pictures, and other files in
both directions. Your phone stores these files in internal
storage or on a removable microSDXC card.
Connecting Your Phone to a
Computer via USB
1. Connect your phone to the PC with a USB cable.
2. Open the Notification Panel and tap .
3. Choose one of the following options:
• Charge only: Charge your phone via USB.
• USB mass storage: Transfer files between your
PC and the microSDXC card in your phone.
• Install driver: Install the driver needed for some
USB connection modes (such as MTP).
•
Media device (MTP): Transfer media files on
Windows
®
, or using Android File Transfer on Mac
®
.
• Camera (PTP): Transfer photos using camera
software.
Connecting with Windows
Media
®
Player
You can sync music with your phone and your computer
installed with Windows Media Player.
1. Connect the phone with your computer via USB and
choose Media device (MTP).
2. Open Windows Media Player and synchronize
music files.
