ZTE Z797C Cell Phone User Manual



Getting Started
6
Getting Started
7
WARNING! Use only ZTE-approved chargers and
cables. The use of unapproved accessories could
damage your phone or cause the battery to explode.
CAUTION: Do not change the built-in rechargeable
battery in your phone by yourself. The battery can only
be changed by ZTE or ZTE authorized service provider.
1. Connect the adapter to the charging port. Ensure
that the adapter is inserted with the correct
orientation. Do not force the connector into the
charging port.
2. Connect the charger to a standard AC power outlet.
If the phone is on, you’ll see a charging icon, such as
or , appear in the Status Bar.
3. Disconnect the charger when the battery is fully
charged.
NOTE: If the battery is extremely low, you may
be unable to power on the phone even when it is
being charged. In this case, try again after charging
the phone for at least 10 minutes. Contact customer
service if you still cannot power on the phone after
prolonged charging.
Extending the Battery Life
Active applications, screen brightness levels, Bluetooth
and Wi-Fi usage, and GPS functionality can drain
your battery. You can follow the helpful tips below to
conserve your battery power.
Reduce the screen backlight time.
Lower the screen brightness.
Turn auto-sync, Wi-Fi, and Bluetooth off when
not in use.
Disable the GPS function when not in use. Most
applications using this function will periodically
query the GPS satellites for your current location;
each query drains your battery.
Powering Your Phone On/O
Press and hold the Power/Lock Key to turn on
your phone.
To turn it off, press and hold the Power/Lock Key
to open the options menu. Tap Power off and then
tap OK.
Restarting the Phone
If the screen freezes or takes too long to respond, try
pressing and holding the Power Key for about 10
seconds to restart the phone.
Setting Up Your Phone for
the First Time
When you first power on your phone after you purchase
it or reset it to factory settings (see Settings – Personal
– Backup and Reset), you may need to set it up before
using it.
1. Tap the language field, select the language you
want, and tap Start. Then follow the prompts to set
up Wi-Fi, Google account, Google location, and
other options.
Locking/Unlocking the
Screen and Keys
Your phone allows you to quickly lock the screen and
keys (put the phone into Sleep mode) when not in use,
and also to turn the screen back on and unlock it when
you need it.
To lock the screen and keys:
To quickly turn the screen off and lock the keys, press
the Power/Lock Key.
NOTE: To save battery power, the phone automatically
turns off the screen after a certain period of time
when you leave it idle. You will still be able to receive
messages and calls while the phone screen is off.
To unlock the screen and keys:
1. Press the Power/Lock Key to turn the screen on.
2. Tap and hold any blank area of the screen. You can
also slide left on the bottom of the screen to access
a few basic functions such as People, Phone, and
Camera.
NOTE: If you have set an unlock pattern, face lock,
PIN, or password for your phone (see Personalizing –
Protecting Your Phone With Screen Locks), you’ll need
to draw the pattern, look at the front-facing camera, or
enter the PIN/password to unlock your screen.
Using the Touch Screen
Your phone’s touch screen lets you control actions
through a variety of touch gestures.
Tap – When you want to type using the on-screen
keyboard, select items on-screen (such as application
and settings icons), or press on-screen buttons,
simply tap them with your finger.
Tap and Hold – To open the available options for
an item (for example, a message or link in a web
page), tap and hold the item.
Swipe or Slide – To swipe or slide means to
quickly drag your finger vertically or horizontally
across the screen.
Drag – To drag, press and hold your finger with
some pressure before you start to move your finger.
While dragging, do not release your finger until you
have reached the target position.
Pinch – In some apps (such as Maps, Browser, and
Gallery), you can zoom in and out by placing two
fingers on the screen at once and pinching them
together (to zoom out) or spreading them apart (to
zoom in).
Rotate the screen – For most screens, you can
automatically change the screen orientation from
portrait to landscape by turning the phone sideways.
