E-16
Removing the TTL cable connector cap
TTL flash shooting is possible by uncapping the TTL cable connector
on this case (PT-023) and connecting the FL-20 flash case (optional
PFL-01) as described in the following procedure.
TTL flash shooting by combining this case (PT-022) and the case for
FL-20 flash (optional PFL-01):
TTL cable
connector cap
Turn counter clockwise.
Remove.
Underwater
TTL cable
Insert into the
connector.
Turn the threaded section of the connector
clockwise lightly until it is stopped.
1
2
1
Remove the TTL cable connector
cap from this case.
❈
The PFL-01 can be used only
with the C-770 Ultra Zoom.
2
Connect the underwater TTL
cable connector, provided with
the PFL-01, to the TTL cable
connector on this case.
---- How to attach the TTL cable connector cap to the case ----
Make sure there is no foreign matter attached to the O-rings inside
the cap and on the TTL cable connector. To secure the cap, gently
turn it clockwise until it stops.
Gently turn the cap
clockwise until it stops.
Put the cap on the case.
