E-25
: •
After inserting the camera into the case, confirm that the
mode dial moves. If it does not move, oil or grease may
have gotten on the mode dial. Wipe it clean.
CAUTION
Try to move the mode dial.
After sealing, turn the mode dial knob and confirm that the mode
dial of the camera is switched.
Setting the camera power to ON and OFF
Move the power switch button and confirm that the camera can be
turned ON and OFF.
Perform the final checks.
Visual Inspection
After closing the case tightly, check the seal between the front and
rear lids and the connection between the port and case to make sure
the O-rings are not twisted, that they sit properly in the grooves, and
that no foreign matter has been caught between the two parts.
Fit the lens cap onto the lens
ring as shown in the figure. Be
sure to remove the lens cap
before shooting.
Mounting and Removing the Lens Cap
: •
Hairs, fibers, and other narrow items are not very apparent,
but they may cause entry of water, so that special attention
is required.
CAUTION
