Dolphin® 9500 Series User’s Guide
Physical
Dimensions: 9500/9550 – 9.6"L x 3.45"W x 1.66"D at display (24.53 x 8.76 x 4.23 cm), 2.7"W x 1.5"D at grip
(6.9 x 3.8 cm)
9501/9551 – 9.7”L x 3.45”W x 2.27”D at display (24.66 x 8.77 x 5.76 cm), 2.7"W x 1.5"D at grip
(6.9 x 3.8 cm)
Weight: 9500 Terminal – Batch: 19.7 oz. (558 gm), WLAN: 20.2 oz. (573 gm), WPAN: 20 oz. (567 gm),
WLAN/WPAN: 20.3 oz. (576 gm)
9501 Terminal – 22.65 oz. (642 gm), all versions
9550 Terminal – Batch: 23.4 oz. (663 gm), WLAN: 23.9 oz. (677.5 gm)
9551 Terminal – 25.8 oz. (732 gm), all versions
Operating
Temperature:
14 to 122°F (-10°C to 55°C)
The terminal can operate in temperatures lower than -20°C with potential degradation in perfor-
mance depending on the application
Storage
Temperature:
-4° to 158°F (-20° to 70°C)
Humidity: 95% humidity, non-condensing
Electrical Static
Discharge:
15 KVA on all surfaces
Impact Resistance: Withstands multiple 5ft. (1.5m) drops onto concrete
Environmental
Resistance:
Independently certified to meet IP64 standards for moisture and particle resistance
Power: Lithium-Ion battery technology – 7.4V, 14.8 watt-hour main battery with hot-swappable design for
fast replacement in the field
Other: Integrated stylus with optional tether and adjustable, removable hand strap
Peripherals &
Accessories
See Dolphin 9500 Series Peripherals on page 3-2.
See Dolphin 9500 Series Accessories on page 3-3.
Regulatory
Approvals
See Compliance Label Locations on page 1-1.
Dolphin 9500 Series Technical Specifications
