Follow the instructions from your service provider.
● Access point name — You obtain the access
point name from your service provider.
● User name — The user name may be needed to
make a data connection, and is usually provided
by the service provider.
● Prompt password — If you must enter the
password every time you log in to a server, or if
you do not want to save your password in the
device, select Yes.
● Password — A password may be needed to
make a data connection and is usually provided
by the service provider.
● Authentication — Select Secure to always send
your password encrypted or Normal to send
your password encrypted when possible.
● Homepage — Depending on the access point
you are setting up, enter the web address or the
address of the multimedia messaging centre.
Select Options > Advanced settings to change
the following settings:
● Network type — Select the internet protocol
type to transfer data to and from your device. The
other settings depend on the selected network
type.
● Phone IP address (for IPV4 only) — Enter the IP
address of your device.
● DNS address — Enter the IP addresses of the
primary and secondary DNS servers, if required
by your service provider. Contact your internet
service provider to obtain these addresses.
● Proxy server address — Enter the address of
the proxy server.
● Proxy port number — Enter the port number
of the proxy server.
WLAN internet access points
Press , and select Tools > Settings >
Connection > Access points > Options > Edit
or New access point.
Follow the instructions from the WLAN service
provider.
● WLAN network name — Select Enter
manually or Search for networks. If you select
an existing network, WLAN network mode and
WLAN security mode are determined by the
settings of its access point device.
● Network status — Define whether the network
name is displayed.
● WLAN network mode — Select Ad-hoc to
create an ad hoc network and to allow devices to
send and receive data directly; a WLAN access
point device is not needed. In an ad hoc network,
all devices must use the same WLAN network
name.
● WLAN security mode — Select the encryption
used: WEP, 802.1x (not for ad hoc networks), or
WPA/WPA2. If you select Open network, no
149
Settings
