Specications
Physical Specications
Size: GPSMAP 5008/5208: 6.8" H x 10.1" W x 4.17" D (173.5 x 256 x 105.9 mm)
GPSMAP 5012/4212: 9.47" H x 13" W x 4.7" D (240.5 x 330 x 119.2 mm)
Weight: GPSMAP 5008/5208: 6 lbs. (2.72 kg)
GPSMAP 5012/5212: 9.5 lbs. (4.3 kg)
Display: GPSMAP 5008/5208: 5" H x 6.73" W (128.2 x 170.9 mm)
GPSMAP 5012/5212: 7.11" H x 9.3" W (180.49 x 235.97 mm)
Case: Fully Gasketed, high-impact plastic and aluminum alloy, waterproof to IEC 529-IPX-7
Temp. Range: 5° to 131° F (-15° to 55° C)
GPS Performance (with GPS 17)
Receiver: Differential-ready 12 parallel channel WAAS-capable receiver
Acquisition Times:
Warm: 15 seconds
Cold: 45 seconds
AutoLocate: 2 minutes
Update Rate: 1/second, continuous
GPS Accuracy:
Position: <15 m (49 ft), 95% typical
Velocity: 0.05 meters/second steady state
WAAS Accuracy:
Position: <3 m (9.8 ft), 95% typical
Velocity: 0.05 meters/second steady state
Dynamics: 6gs
Power:
Source: 10-35 VDC
Usage: 5008/5208: 35 W max. at 10 VDC
5012/5212: 40 W max at 10 VDC
Fuse: 7.5 A, 42 V fast-acting
NMEA 2000 Specications:
Load Equivalency Number (LEN): 2
Unit Draw: 75 mA max
