4 Phone overview
The following illustration shows the phone in closed position. With the phone closed, the keys are locked
to prevent accidental key presses.
1. Jack for hands-free headset only (sold separately).
2. Indicator light.
3.
Volume key for raising or lowering speaker volume.
4. External screen for displaying time, caller ID, signal, and
battery strength.
5. Jack for AC adapter (included) and data cable (sold separately).
6.
Camera key for activating camera mode.
7. External speaker.
Warning: Inserting an accessory into the incorrect jack damages
the phone.
Putting on wrist strap
To put on a wrist strap:
1. With the back cover
open, thread the strap
through the eyelet at the
top of the phone.
2. Insert the other end of
the strap into the
beginning end loop and
tighten the strap.
Common keys
The following list the frequently-pressed keys.
Throughout this user guide, these keys are
referred as follows:
Navigation key
OK key
Left softkey
Right softkey
Send key (also referred to as the Call key)
End key (also referred to as the Power key)
Back key
Speakerphone key
82-K6572-1EN.book Page 4 Sunday, June 15, 2008 9:47 PM
