Adding and Replacing Parts 161
3
Holding the metal bracket by the sides, slide the bracket toward the back
of the Tablet-PC to dislodge the bracket from the two metal clips and set
the bracket aside.
4
Use the pull-tab to disconnect the hard drive cable from the system board
connector and remove the hard drive from the Tablet-PC.
Installing the Hard Drive
1
Follow the procedures in "Before You Begin" on page 155.
1 captive screws (2) 2 metal bracket
3 hard drive 4 securing tabs (2)
1 pull-tab 2 hard drive
3 alignment ribs
1
2
3
