Adding and Replacing Parts 195
Installing the Pen and Whip Antenna Assembly
1
Seat the pen-missing cable and whip antenna cable into their routing
channels. Route the pen-missing cable through the base hooks by the grip
area. Use tape to hold the cable down through the base hooks.
2
Tighten the two M2 x 3-mm screws.
3
Install the system board (see "Installing the System Board" on page 191).
4
Install the palm rest (see "Installing the Palm Rest" on page 189).
5
Install the display assembly (see "Installing the Display Assembly" on
page 182).
6
Install any Mini-Cards (see "Installing a Mini-Card" on page 173).
7
Install the keyboard (see "Installing the Keyboard" on page 177).
8
Install the hinge cover (see "Installing the Hinge Cover" on page 175).
Wireless Switch
CAUTION: Before performing the following procedures, follow the safety
instructions in your
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching a connector on the back panel of the
Tablet-PC.
NOTICE: To avoid damaging the system board, you must remove the main battery
before you begin working inside the Tablet-PC.
Removing the Wireless Switch
1
Follow the procedures in "Before You Begin" on page 155.
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 174).
3
Remove the display assembly (see "Removing the Display Assembly" on
page 179).
1 pen and whip antenna assembly 2 pen-missing cable
3 M2 x 3-mm screws (2) 4 whip antenna cable
5 base
