192 Adding and Replacing Parts
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 174).
3
Remove the display assembly (see "Removing the Display Assembly" on
page 179).
4
Remove the keyboard (see "Removing the Keyboard" on page 176).
5
Remove any installed Mini-Cards (see "Removing a Mini-Card" on
page 171).
6
Remove the palm rest (see "Removing the Palm Rest" on page 186).
7
Remove the system board (see "Removing the System Board" on
page 189), and place it upside-down on a clean work surface.
8
Disconnect the fan cable from the system board.
9
Using a #0 Phillips screwdriver, remove the four M2 x 3-mm screws, and
lift the fan from the system board.
2
1
3
