Adding and Replacing Parts 179
2
Connect the coin-cell battery connector to the connector on the system
board.
3
Install the keyboard (see "Installing the Keyboard" on page 177).
4
Install the hinge cover (see "Installing the Hinge Cover" on page 175).
Display Assembly
CAUTION: Before performing the following procedures, follow the safety
instructions in your
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching a connector on the back panel of the
Tablet-PC.
NOTICE: To avoid damaging the system board, you must remove the main battery
before you begin working inside the Tablet-PC.
Removing the Display Assembly
1
Follow the procedures in "Before You Begin" on page 155.
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 174).
3
Remove the keyboard (see "Removing the Keyboard" on page 176).
4
Remove any installed Mini-Cards (see "Removing a Mini-Card" on
page 171).
5
Use the pull-tab to disconnect the display cable from the system board.
