HTC LIBR100 Cell Phone User Manual



102 Appendix
A.1 Specifications
System information
Processor/
Chipset/Speed
QUALCOMM
TM
MSM 7500, 400 MHz
Memory • ROM-Nand Flash: 128 MB (Standard)
• RAM: 64 MB DDR
Figures are the total ROM and RAM memory available for use and storage. Since the memory is shared
by the Operating System, applications, and data, the actual available memory is less than what is written
.
Operating system Microsoft® Windows Mobile® 6 Standard
Display
Type 2.4” QVGA Transmissive LCD with white LED backlight
Resolution 240 x 320 dots resolution at 65K Colors
Orientation Portrait and Landscape both
CDMA/EVDO Dual-band module
Functionality CDMA2000
Mode Dual band: 800 and 1900 MHz
Antenna Internal
Camera module
Type 2.0 Megapixels CMOS with fixed lens
Resolution UXGA: 1200 x 1600
SXGA: 960 x 1280
VGA: 480 x 640
QVGA: 240 x 320
QQVGA: 120 x 160
Connection
I/O port HTC ExtUSB™ : an 11-pin mini-USB and audio jack in one
(ExtUSB is a proprietary connection interface that is trademarked by HTC)
Bluetooth V 1.2 with A2DP support, Class 2 transmit power
Audio
Microphone/
speaker
Built-in microphone and speaker, Hands-free
Headphone AAC/AMR/WMA/WAV/MP3 codec
Physical
Dimension 103.5 mm(L) x 51 mm(W) x 19 mm(T)
Weight 138g with battery pack
