Nokia E71x Cell Phone User Manual



10
You can extend the available memory with a microSDHC or microSD card with up to 8 GB
memory. Optimal performance is with a 4GB microSD card. You can insert or remove a
microSDHC or microSD card without switching the phone off.
To maximize the performance of your device, it is recommended that no more than 100 files
are stored in any folder.
Insert the microSD card
The memory card may be supplied with the phone,
and may already be inserted.
1. Open the cover of the memory card slot.
2. Insert the memory card in the slot with the
contact area first. Make sure that the contact
area is facing the connectors on the device.
3. Push the card in until it locks into place
4. Close the cover.
Important: The microSD card must be inserted in the slot with the gold-colored
area facing the front of the device.
Eject the microSD card
Important: Do not remove the memory card in the middle of an operation when
the card is being accessed. Removing the card in the middle of an operation may
damage the memory card as well as the device, and data stored on the card may be
corrupted.
1. Press the power key briefly, and select Remove memory card.
2. Open the cover of the memory card slot.
3. Press the end of the memory card to release it from the memory card slot.
4. Close the cover.
After you install applications to a compatible memory card, installation files (.sis, .sisx)
remain in the device memory. The files may use large amounts of memory and prevent you
from storing other files. To maintain sufficient memory, use Nokia PC Suite to back up
installation files to a compatible PC, then use the file manager to remove the installation
files from the device memory. See
"Install an application," p. 47. If the .sis file is a
message attachment, delete the message from the Messaging inbox.
Charge the battery
Your battery has been precharged, but the charging levels may vary.
