- 159 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
12. EXPLODED VIEW & REPLACEMENT PART LIST
by SBOM standard on GCSC
Level LocationNo. Description PartNumber Spec Remark
1 AAD000000 Addition Assembly - AAAY0524401 LG-C320 BOOWA ZZ:Without Color -
2 ACGA00 Cover Assembly,Battery - ACGA0048201 LG-C320i IDNWA WA:White -
3 MCJA00 Cover,Battery MCJA0120401 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
3 MPBN00 Damper,Speaker MPBN0093201 COMPLEX LG-C320i IDNWA WA:White COMPLEX, (empty), , , , ,
2 MFL053800 Manual,Operation MFL67003501
COMPLEX LGC320.ABOOWA ZZ:Without Color LGC320 manual for
BOO
1 AGF000000 Package Assembly - AGF75960001
LGC320.ABOOWA ZZ:Without Color LGC320 BOO(TR3/STD
UB/1160*1160 Pallet/600ea)
2 MAY084000 Box,Unit MAY64811601
COMPLEX LGC320.ABOOWA ZZ:Without Color LGC320 BOO(TR3
STD UB)
2 MAF086500 BAG,VINYL(PE) MBAD0005204 LG-LX260 SPRAG AG,ZZ,COMPLEX, (empty), , , , ,
2 AGJ000000 PALLET ASSY - APLY0002405 KP110 OPTBK BK,ZZ,TR3 Australia(600ea) Pallet Assy
3 MBEC00 BOX,CARTON MBEC0002002 KG270 CIS BK,ZZ,BOX, TW
3 MCCL00 Cap,Box MCCL0000402 COMPLEX KG270 CIS ZZ:Without Color BOX,TW, PBO PBOTW
3 MPCY00 Pallet MPCY0015703
COMPLEX TU500 TELBK SV:Silver
COMPLEX,(empty),1160,1160,126,
3 MSCA00 SLEEVE,BOX MSCA0000701 MG230d CLA TS,ZZ,BOX, TW
2 MAY047100 Box,Master MBEE0059803 COMPLEX KP100 GBRLA ZZ:Without Color -
2 MEZ003500 Label,Barcode MLAC0004541 COMPLEX HB620 KPNBK ZZ:Without Color -
2 MEZ047200 LABEL,MASTER BOX MLAJ0004402
CG300 CGR DG,ZZ,LABEL,MASTER BOX(for CGR TDR 2VER.
mbox_label)
2 MEZ000000 LABEL MLAZ0050901 KU990 GBRBK BK,ZZ,PRINTING, (empty), , , , ,
1 APEY00 PHONE - APEY0988401 LG-C320 BOOWA WA,ZZ,
2 MEZ002100 Label,Approval MLAA0062311 COMPLEX KB770 DEUBK ZZ:Without Color -
2 ACGY00 COVER ASSY,EMS - ACGY0088801 LG-C320 BOOWA WA,ZZ,
3 ABFZ00 Bracket Assembly - ABFZ0028101 LG-C320 BOOWA ZZ:Without Color -
4 MEV000000 Insulator MIDZ0281601
COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX, (empty), ,
, , ,
4 MCQ049800 Damper,Motor MPBJ0079001 COMPLEX LG-C320i IDNWA WA:White COMPLEX, (empty), , , , ,
4 MJN000000 Tape MTAZ0358201 COMPLEX LG-C320i IDNWA WA:White COMPLEX, (empty), , , , ,
4 MCQ015700 Damper,Connector MPBU0114101 COMPLEX LG-C320i IDNWA WA:White COMPLEX, (empty), , , , ,
12.2 Replacement Parts
Note: This Chapter is used for reference, Part order is ordered
<Mechanic component>
