- 169 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
12. EXPLODED VIEW & REPLACEMENT PART LIST
Level LocationNo. Description PartNumber Spec Remark
6 J501 Jack,Phone ENJE0007601
KJA-PH-0-0176 1P 4P ANGLE R/TP 4mM BLACK 6P - KSD CO.,
LTD
6
C201,C205,C
206,C311
Capacitor,Ceramic,Chip ECCH0005604
GRM188R60J106M 10000000 pF,6.3V,M,X5R,TC,1608,R/TP,0.8 mm
MURATA MANUFACTURING CO.,LTD.
6 CN401 connector,I/O ENRY0008801
GU073-5P-SD-E1500 GU073-5P-SD-E1500,5,mm,ANGLE LS Mtron
Ltd.
6 J301 Card Socket ENSY0025901
GCA26A-8S-H16-M-E1000 SIM 8P ANGLE SMD R/TP - LS Mtron
Ltd.
6 SW101 Connector,RF ENWY0008701
MS-156C NONE STRAIGHT SOCKET SMD T/REEL AU 50OHM
400mDB HIROSE KOREA CO.,LTD
6 CN402
Connector,Terminal
Block
ENZY0028601
04-9248-003-017-829+ 3P 2.50MM STRAIGHT SMD R/TP -
KYOCERA ELCO KOREA SALES CO.,LTD.
6 Q501 FET EQFP0007601
KTJ6131E P-CHANNEL MOSFET -30V +-20 -0.05A 20OHM 100mW
ESM R/TP 3P KEC CORPORAITION
6
C251,C720,C
724
Capacitor,Ceramic,Chip ECCH0007804
CL05A225MP5NSNC 2.2uF 20% 10V X5R -55TO+85C 1005 R/TP
0.5MM SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 R703 Resistor,Chip ERHY0000128
MCR01MZP5F1502 15KOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R406 Resistor,Chip ERHY0000185 MCR01MZP5F8200 820OHM 1% 1/16W 1005 R/TP - ROHM.
6 R110,R111 Resistor,Chip ERHY0000241
MCR01MZP5J102 1KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
R307,R308,R
309,R310,R3
11
Resistor,Chip ERHY0000275
MCR01MZP5J563 56KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R205 Resistor,Chip ERHY0003201 MCR01MZP5F1001 1KOHM 1% 1/16W 1005 R/TP - ROHM.
6 R262 Resistor,Chip ERHY0009505
MCR006YZPJ103 10KOHM 5% 1/20W 0603 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 C115,C265 Capacitor,Ceramic,Chip ECZH0000803
C1005C0G1H020CT000F 2pF 0.25PF 50V NP0 -55TO+125C 1005
R/TP - TDK KOREA COOPERATION
6 R207 Resistor,Chip ERHZ0000486
MCR01MZP5J473 47KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R107 Resistor,Chip ERHY0009586
MCR006YZPF2201 2.2KOHM 1% 1/20W 0603 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R263 Resistor,Chip ERHY0024201 MCR01MZP5F6041 6040 ohm,1/16W,F,1005,R/TP ROHM.
6 R404 Resistor,Chip ERHZ0000201
MCR01MZP5F1000 100OHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R201,R260 Resistor,Chip ERHZ0000204
MCR01MZP5F1003 100KOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R510,R511 Resistor,Chip ERHZ0000205
MCR01MZP5F1004 1MOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
L103,L104,
L117
Inductor,Multilayer,Chip ELCH0004706
1005GC2T10NJ00 10NH 5% 0V 250mA 0.42OHM 2.5GHZ 8 NON
SHIELD 1 1.0X0.5X0.5MM R/TP PILKOR ELECTRONICS LTD.
