4. TROUBLE SHOOTING
Audio Sub system IC501TP1_C506TP1_C507
GND
HS_R
SPK_N
SPK_P
MUIC_AUD_FM_I2C_SCL
MUIC_AUD_FM_I2C_SDA
SPK_OUT_
N
SPK_OUT_P
HS_OUT_R
HS_OUT_L
HS_L
WM9093 is possible to 1.8 & 2.6 IO When HPVDD is 1.8V
