12. EXPLODED VIEW & REPLACEMENT PART LIST
Level LocationNo. Description PartNumber Spec Remark
4 ABFZ01 BRACKET ASSY - ABFZ0023401 LG-MN240 MTP LS,ZZ,
5 MBFZ00 BRACKET MBFZ0043001 LG-MN240 MTP LS,ZZ,COMPLEX, (empty), , , , ,
5 MTAB00 TAPE,PROTECTION MTAB0381101 LG-MN240 MTP LS,ZZ,COMPLEX, (empty), , , , ,
4 ACGK00 Cover Assembly,Front - ACGK0169801 LG-C320i IDNWA ZZ:Without Color LG-C320i IDNWA
5 MCJK00 Cover,Front - MCJK0135101 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
6 MICE00 INSERT,NUT MICE0016903 MECH_COMMON ZY,ZZ,PRESS, STS, , , , ,
5 MPBZ01 Damper MPBZ0320601 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
5 MPBZ00 Damper MPBZ0320801 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
5 MPBZ02 Damper MPBZ0366401 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
4 ACGU00 Cover Assembly,Lower - ACGU0007201 LG-C320i IDNWA ZZ:Without Color LG-C320i IDNWA
5 MCJY00 Cover,Lower MCJY0008701 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
5 MMAA00 MAGNET,SWITCH MMAA0011201 LG-LU1600 LGTWW WW,ZZ,COMPLEX, (empty), , , , ,
5 MPBZ01 PAD MPBZ0260601 LG-MN240 MTP LS,ZZ,COMPLEX, (empty), , , , ,
5 MPBZ PAD MPBZ0260901 LG-MN240 MTP LS,ZZ,COMPLEX, (empty), , , , ,
5 MPBZ02 Damper MPBZ0320401 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
4 GMEY01 Screw,Machine GMEY0017801
GMEY0017801 BH + 1.4mM 1.4mM MSWR FZB N - KUMGANG
SCREW CO., LTD
4 GMEY02 Screw,Machine GMEY0019201
GMEY0019201 FH + 1.4mM 1.8mM SWCH FZW N N KUMGANG
SCREW CO., LTD
4 MCCH00 Cap,Screw MCCH0165101 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
4 MEV000002 Insulator MEV63651701 COMPLEX LGC320.ABOOWA BL:Blue insulator, FPCB
4 MDS000000 Gasket MGAZ0112501 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
4 MEV000001 INSULATOR MIDZ0259401 LG-MN240 MTP LS,ZZ,COMPLEX, (empty), , , , ,
4 MCQ000000 Damper MPBZ0357401
COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX, (empty), ,
, , ,
6 MJN000000 Tape MTAZ0368001
COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX, (empty), ,
, , ,
6 MCQ015700 Damper,Connector MPBU0113901
COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX, (empty), ,
, , ,
6 ADCA01 Dome Assembly,Metal ADCA0118401 LG-C320i IDNWA ZZ:Without Color LG-C320i IDNWA
5 MCQ000000 Damper MPBZ0349901
COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX, (empty), ,
, , ,
5 ACKA00 Can Assembly,Shield - ACKA0035801 LG-C320i IDNWA ZZ:Without Color -
6 MCBA00 Can,Shield MCBA0086901 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
5 MEV000000 Insulator MIDZ0284101 COMPLEX LG-C320i IDNWA ZZ:Without Color COMPLEX,(empty),
