- 31 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. TECHNICAL BRIEF
3.2.3 Charging control
C320 use single Charger.
- Single charger has five mode like “ OFF / TRICKLE / ISET / USB500 / FACTORY mode”.
- Single Charger is working as ISET mode in case of CC(Constant Current), CV(Constant Voltage) mode,
as USB 500mode in case of USB Charging.
- FACTORY mode is working only for Factory use.
p
j
j
ylT
kGG
kGuv{G
VBUS_LDO_4V9
I
ND
CHG_STS_N
MUIC_IO_M
MUIC_IO_P
MUIC_ACC_ID
