- 170 -
LGE Internal Use Only Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
12. EXPLODED VIEW & REPLACEMENT PART LIST
Level LocationNo. Description PartNumber Spec Remark
6 R601,R602 Resistor,Chip ERHZ0000206
MCR01MZP5F10R0 10OHM 0.1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R807 Resistor,Chip ERHZ0000213
MCR01MZP5F1203 120KOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
R103,R104,R
112,R113
Resistor,Chip ERHZ0000219
MCR01MZP5F1500 150OHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R405 Resistor,Chip ERHZ0000236
MCR01MZP5F2001 2KOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R403 Resistor,Chip ERHZ0000318
MCR01MZP5F8062 80.6KOHM 1% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
R272,R302,R
303,R304,R5
01
Resistor,Chip ERHZ0000405
MCR01MZP5J103 10KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R282,R402 Resistor,Chip ERHZ0000406
MCR01MZP5J104 100KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R101,R102 Resistor,Chip ERHZ0000434
MCR01MZP5J1R0 1OHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R301 Resistor,Chip ERHZ0000438
MCR01MZP5J203 20KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
R219,R266,R
267,R268,R2
69,R401,R50
2
Resistor,Chip ERHZ0000443
MCR01MZP5J222 2.2KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R808,R809 Resistor,Chip ERHZ0000465
MCR01MZP5J332 3.3KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R102,R114 Resistor,Chip ERHZ0000473
MCR01MZP5J390 39OHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 C119 Capacitor,Ceramic,Chip ECCH0000143
MCH155CN102KK 1nF 10% 50V X7R -55TO+125C 1005 R/TP -
ROHM Semiconductor KOREA CORPORATION
6 R264,R265 Resistor,Chip ERHZ0000484
MCR01MZP5J471 470OHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R273 Resistor,Chip ERHZ0000490
MCR01MZP5J510 51OHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 U802 IC,Bus Controller EUSY0300008 PP2106M3 1.8/2.6V 1mA - MLF R/TP 28P - G5 CORPORATION
6 U803 IC,Analog Switch EUSY0347001
DG2735DN-T1-E4 MiniQFN-10L ,10 PIN,R/TP ,1.8X1.4X0.55,0.6
Dual SPDT Analog Switch ,; ,IC,Analog Switch VISHAY
INTERTECHNOLOGY ASIA PTE LTD
6 U301 IC,MCP,NAND EUSY0347506
H8BCS0SI0BAR-46M NAND/2G SDRAM/1G 1.7VTO1.9V
14.0x10.0x1.2 TR 149P - - - HYNIX SEMICONDUCTOR INC.
6 U501
IC,LDO Voltage
Regulator
EUSY0355501
RP103K181D-TR-F 1.7V TO 5.25V 1.85V 400mW DFN R/TP 4P -
RICOH COMPANY, LTD.
6 U701 Module,Assembly EUSY0385901
TEA5991UK TEA5991_UK,WL-CSP(BSC),20,R/TP,FM Tuner
(RDS),2.6*2.6*0.64 ST-Ericsson Asia Pacific Pte Ltd
