- 173 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
12. EXPLODED VIEW & REPLACEMENT PART LIST
Level LocationNo. Description PartNumber Spec Remark
6
C208,C211,C
212,C213,C2
14,C215,C21
6,C217,C218
,C219,C220,
C221,C222,C
223,C229,C2
31,C235,C23
6,C305,C306
,C307,C308,
C309,C310,C
605,C606,C7
01,C709
Capacitor,Ceramic,Chip ECCH0009101
C0603X5R0J104KT00NN 0.1uF 10% 6.3V X5R -55TO+85C 0603
R/TP - TDK CORPORATION
6 C722,C723 Capacitor,Ceramic,Chip ECCH0009514
MCH032A(AN)100DK 10pF 0.5PF 25V X7R -55TO+125C 0603 R/TP
- ROHM.
6
C105,C117,C
118,C122,C1
30,C135,C51
9,C520,C521
Capacitor,Ceramic,Chip ECZH0000830
C1005C0G1H330JT000F 33pF 5% 50V NP0 -55TO+125C 1005
R/TP - TDK KOREA COOPERATION
6
C134,C312,C
401,C409,C4
11
Capacitor,Ceramic,Chip ECZH0001215
C1005X5R1A105KT000F 1uF 10% 10V X5R -55TO+85C 1005 R/TP
- TDK KOREA COOPERATION
6 C506,C507 Capacitor,Ceramic,Chip ECZH0001217
GRM155R60J474K 470nF 10% 6.3V X5R -25TO+70C 1005 BK-DUP
- MURATA MANUFACTURING CO.,LTD.
6
C204,C261,C
262,C263,C2
64,C266,C27
6,C299,C302
,C405,C413
Capacitor,Ceramic,Chip ECZH0003103
GRM36X7R104K10PT 100nF 10% 10V X7R -55TO+125C 1005 R/TP
- MURATA MANUFACTURING CO.,LTD.
6 C508,C509 Capacitor,Ceramic,Chip ECZH0003126
GRM155R71A393K - - - - -55TO+125C - - - MURATA
MANUFACTURING CO.,LTD.
6 C268 Capacitor,Ceramic,Chip ECZH0025916
GRM0335C1E330J 33pF 5% 25V NP0 -55TO+125C 0603 R/TP -
MURATA MANUFACTURING CO.,LTD.
6
LD801,
LD802
LED,Chip EDLH0013701
WHITE 2.9~3.2 20mA X(0.264~0.311) Y(0.248~0.315) 110mW
3.8*1.0*0.4t 3810 R/TP 2P -
6 CN801 Connector,BtoB ENBY0042701
GB042-54S-H10 54P 0.4MM STRAIGHT SOCKET SMD R/TP 1M -
LS Mtron Ltd.
6 CN260 Connector,BtoB ENBY0045201
AXT610124 10P 0.4MM STRAIGHT HEADER SMD R/TP 1M - BJ
PANASONIC ELECTRONIC PARTS CO.,LTD
6 R101 Resistor,Chip ERHY0000254
MCR01MZP5J472 4.7KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6
R105,R106,R
107,R108,R1
09,R110
Resistor,Chip ERHZ0000402
MCR01MZP5J100 10OHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
6 R282,R402 Resistor,Chip ERHZ0000406
MCR01MZP5J104 100KOHM 5% 1/16W 1005 R/TP - ROHM
Semiconductor KOREA CORPORATION
