12. EXPLODED VIEW & REPLACEMENT PART LIST
by SBOM standard on GCSC
Level LocationNo. Description PartNumber Spec Remark
4 EBR070500 PCB Assembly,Flexible - EBR72655001 LGC320.ABOOWA FLEXIBLE 1.0
5 EBR070400
PCB Assembly,
Flexible,SMT
- EBR72681501 LGC320.ABOOWA FLEXIBLE 1.0
6 EAX010700 PCB,Flexible SPCY0247101
SPCY0247101 LG-C320i IDNWA,FLEXIBLE,E,POLYI,0.15
mm,DOUBLE SI FLEX CO., LTD
6 EBR070200
PCB Assembly,
Flexible,SMT Bottom
- EBR72655201 LGC320.ABOOWA FLEXIBLE 1.0
7 CN101 Connector,BtoB ENBY0052901
55909-0274 20P 0.40MM STRAIGHT MALE SMD R/TP 1.5M -
HANKOOK MOLEX
7 S101 Socket,Card ENSY0023601
SCHA4B0402 Micro-SD 8P ANGLE SMD R/TP - ALPS ELECTRIC
KOREA CO.,LTD.
6 EBR070300
PCB Assembly,
Flexible,SMT Top
EBR72681601 LGC320.ABOOWA FLEXIBLE 1.0
4 EAU010000 Motor,DC SJMY0007104 3V 80mA 0A 12KRPM 0RPM 0SEC 0GF.CM 0OHM
4 EAB010100 Speaker Module SUSY0027617 SI-C320-P LG-C320i IDNWA BUJEON ELECTRONICS CO., LTD
4 SNGF00 Antenna,Helical SNGF0064202
ACD-00094 3.0,-2 dBd,GSM Quad carrier type,QUAD,-2.0,50,3.0
MOBITECH CORPORATION
6 RAB040100 Film,Inmold BFAA0127401
BFAA0127401 ; ,BLACK , , , BLACK , , , NISSHA PRINTING CO.,
LTD
4 SURY00 Receiver SURY0010114
BWBR1207L-04B-P 30mW 32OHM 105DB 0HZTO0HZ WIRE -
BUJEON ELECTRONICS CO., LTD
4 SACY00 PCB Assembly,Flexible - SACY0127201 LG-C320 BOOWA FLEXIBLE 1.0
5 SACE00
PCB Assembly,
Flexible,SMT
- SACE0114501 LG-C320 BOOWA FLEXIBLE 1.0
6 EAX010700 PCB,Flexible SPCY0246901
SPCY0246901 LG-C320i IDNWA,FLEXIBLE,D,POLYI,.12
mm,DOUBLE SI FLEX CO., LTD
6 SACC00
PCB Assembly,
Flexible,SMT Bottom
SACC0085002 LG-C320 BOOWA FLEXIBLE 1.0
6 SACD00
PCB Assembly,
Flexible,SMT Top
- SACD0098702 LG-C320 BOOWA FLEXIBLE 1.0
7 C101,C102 Varistor SEVY0005201
EVLC5S02050 5.5V 0% 50F 1.0*0.5*0.6 - SMD R/TP AMOTECH
CO., LTD.
7
FB101,
FB102
Inductor,Multilayer,Chip ELCH0004727
1005GC2TR10J00 100NH 5% 0V 100mA 2.3OHM 600MHZ 8 NON
SHIELD 1 1.0X0.5X0.5MM R/TP PILKOR ELECTRONICS LTD.
7 CN102 Connector,BtoB ENBY0040401
GB042-50P-H10-E3000 50P 0.4MM STRAIGHT PLUG SMD R/TP
1M - LS Mtron Ltd.
7
VA101,
VA102
Varistor SEVY0003901
EVL5M02200 5.5V 0% 480F 1.0*0.5*0.6 NONE SMD R/TP
AMOTECH CO., LTD.
12.2 Replacement Parts
Note: This Chapter is used for reference, Part order is ordered
<Main component>
