Troubleshooting
Issue 1 October 1998
6-15
Statistics Menu Information
Introduction
The Switch Management Interface allows the administrator
to obtain detail status information on a specific Switch
Card in the Rack. If there are any problems with the card or
the connection, the status menu will display the error by
incrementing the Value field for the specific error code.
The Value digit is a counter and will continue to display
errors, until the card’s stats are reset or until the card has
been re-started.
Procedure
1. Click Hardware. All cards installed in the Rack are displayed along
with slot position, card model, and the user group assigned to the card.
2. Select a Switch Card and click Statistics. The following information is
displayed: Code (see Figure 6.2 below), Value, and Description
Note: There are two buttons available to the administrator at this point.
Update Now button Updates the statistics to the current count
Reset Stats button Will reset the stats to zero for selected card.
Figure 6.2. Statistics menu
