Lucent Technologies 3000 Carrying Case User Manual



Configuration
5-24 Issue 1 October 1998
How to Assign User Groups to Cards
Introduction
In order for a Switch Card to use passwords from a
particular user group, that user group must be assigned and
uploaded to that Switch Card.
Procedure
1. Click Hardware tab and select the desired card.
2. If not already logged in, enter the administrator password.
(default password is 000000) Click Next.
Note: To change the administrator password, see page 5-15.
3.
Click the Passwords tab (see Figure 5.15 on the next page) on the right
side of the screen. Select the desired user group from the drop down list.
Note: Any updated information will not be stored in the Switch Card until the
passwords have been uploaded. (see page 5-26)
Setup tips
Many organizations do not have more than 100 users sharing a single
Rack. Therefore, it is common practice to set up a single user group,
have all approved remote users belong to that user group, and upload the
same user group to all Switch Cards.
If each remote user can access one and only one specific Switch Card,
you must set up a user group for each individual user, and upload these
separate user groups to the specific Switch Cards.
