Product Overview
1-2 Issue 1 October 1998
Product Overview
Introduction
This chapter provides a product overview that includes:
Product summary
Product descriptions
Product
Summary
The DEFINITY
Extender Model 3000 is a high-density
switch-side device that connects to the DEFINITY ECS’
digital line interface. The Rack can be configured with up
to 12 Switch Cards, which are sold separately.
The Rack can be configured with up to 12 Switch Cards,
in any combination Model 3100 Analog Switch Cards, or
the Model 3200 ISDN Switch Cards.
Note: The Model 3200 ISDN Switch Card is not yet
available.
Analog Switch Cards extend one DEFINITY ECS
terminal per card for a total of 12 users per Rack, while the
ISDN Switch Cards can extend two DEFINITY ECS
terminals per card for a total of up to 24 users per Rack.
To use the Switch Cards to extend a terminal, the remote
user must have an accompanying remote module extender
(sold separately). See Table 1-1, next page, for the remote
module required to connect to the corresponding Switch
Card.
