Specifications
2-4 Issue 1 October 1998
DEFINITY
Extender Model 3100 Card Specifications
Specification Description
Approvals NRTL/C, FCC, Parts 15 and 68, Class A,
Industry Canada
Communication
Modem Connect Rates 14.4, 16.8, 19.2, 21.6, 24.0, 26.4, 28.8,
31.2, 33.6Kbps
Voice Compression G.723.1 (6.3Kbps)
Data Type Rockwell V.34 internal modem
Data Impedance 600 Ohms
Data Tx Level –10 dBm (+1 dBm/–3 dBm)
Data Rx Sensitivity – 9 to - 43 dBm
User Data Port
Data Type RS-232, using COMA on Rack.
Data Rate Settings 2.4 Kbps, 4.8 Kbps, 9.6 Kbps, 19.2 Kbps,
38.4 Kbps, 57.6Kbps, 115.2 Kbps
Parity Setting None, Even, Odd
Data Bits Setting 7, 8
Stop Bits Setting 1 or 2
Table 2-2. Analog Switch Card Specifications
