Rack Installation
3-2 Issue 1 October 1998
Rack Installation
Introduction
This chapter provides the following information:
Pre-installation requirements
How to install the Rack hardware
How to wire the Rack backplane for connections to the
PSTN and DEFINITY ECS.
Complete power-up sequence
Lucent Supplied Equipment
DEFINITY
Extender Model
3000
DEFINITY
Extender Model
3100
(sold separately
from Rack
One twelve slot Rack mountable chassis
One power cord
One System Administrator’s Guide
Switch Management Interface software (2 disks)
One Analog Switch Card
One Quick Installation Guide
Operational
Considerations
The Rack is to be used with DEFINITY ECS
Version 3, Release 3 or later.
Order a separate central office (CO) line at each
remote module location.
Each Switch Card will need a digital port
(extension) from the DEFINITY ECS, and an
analog line from the (CO) or the DEFINITY ECS.
Be sure that the DEFINITY ECS digital port to
which the Switch Card is connected is
programmed correctly for the telephone type
being used at the remote location.
Remote Modules, desksets and communication
line cords are NOT supplied with this system.
Use two-wire digital display phones only.
