Rack Installation
Issue 1 October 1998
3-3
Customer Supplied Equipment
NOTE: DEFINITY ECS telephones are not supplied with either the Switch
Cards or the remote modules. These items must be ordered separately.
Contact your Lucent Technologies representative for information.
You must supply the following for installation:
DEFINITY ECS two-wire, 24-port TN-2224 circuit pack or the older 16
port TN2181.
Any additional DEFINITY ECS circuit packs needed (see the DEFINITY
Communications System Generic 3, Installation for Single-Carrier
Cabinets manual, document #555-230-894, comcode #107595423, for
further information).
An adapter to convert to 120 VAC if you are connecting the Rack to a
240 VAC outlet.
Power and central office line suppresser. Lucent Technologies
recommends the 147C AC/CO Line Surge Protector (#8310-006).
Contact your Lucent Technologies representative for ordering
instructions.
Four 50-pin female connectors (two connectors for every six Switch
cards)
A computer for installing and using the Switch Management Interface.
Minimum requirements as shown in Table 3.0 below:
Minimum
Processor 486 DX2 66MHZ
RAM 16MB
Operating
Systems
WIN 95, WIN 98, or
Windows NT 4.0
Disk Drive 3 ½ Floppy Disk
Free Disk
Space
6.0 MB
Table 3-0. Minimum PC Requirements
