1 — Cellular antenna
2 — Antenna for Bluetooth technology, wireless LAN,
and DVB-H; GPS receiver
Note that the Bluetooth, WLAN, GPS, and DVB-H
antennas are located in the back cover of your device.
If you change the back cover, check that the new cover
includes these antennas, otherwise these connections
stop working.
Charge the battery
1. Connect a compatible charger to a
wall outlet.
2. Connect the power cord to the
device. If the battery is completely
discharged, it may take a while
before the charging indicator
starts scrolling.
3. When the battery is fully charged, the charging
indicator stops scrolling. Disconnect the charger
from the device, then from the wall outlet.
Tip: Disconnect the charger from the wall outlet
when the charger is not in use. A charger that is
connected to the outlet consumes power even
when it is not connected to the device.
Memory card
Use only compatible microSD cards
approved by Nokia for use with this device.
Nokia uses approved industry standards for
memory cards, but some brands may not be fully
compatible with this device. Incompatible cards may
damage the card and the device and corrupt data
stored on the card.
Insert the memory card
Keep all memory cards out of the reach of small
children.
A memory card may be already inserted in the device.
If not, do the following:
1. Place your finger in the recess beside the door of
the memory card slot, and lift the door. Pull the door
to the left to reveal the hinge, and swing the door
to the side.
16
Get started
