4.BASIC FUNCTIONS
28
4.3.2 Post Dial
1) ipLDK-24/100
→
CO Line Access Code (9, 8+XX or 88+XX)
→
Phone number
→
Connection ;
(XX means CO line number).
2) ipLDK-300/300E
→
CO Line Access Code (9,8+XX or 88+XXX)
→
Phone number
→
Connection ;
(XX means CO Group Number, XXX means CO line number).
You may dial telephone number after pressing
TALK
( ) button. When pressing CO line
access code (9, 8 + XX, or 88 + XX), CO line dial tone is heard. Every time pressing each
button, it is displayed on the LCD. If you dial a number late, “
DIALING TOO LATE
” message is
displayed on the LCD.
Note
In case of ipLDK-24/100/300/300E system, if handset was registered by ‘TYPE 3’, it is
displayed 12 digits per line on the LCD (This feature is available when MPB version of
ipLDK-100/300/300E is 1.0Ba above and when MPB version of ipLDK-24 is available on all
version. Please refer to ‘9.2 Subscription’ for details.
z Press button. Connection tone is heard and
phone
(
) icon is displayed on
the LCD.
z Dial CO line access code.
Î ipLDK-24/100 (9, 8 + XX, or 88 + XX).
Î ipLDK-300/300E (9, 8 + XX, or 88 + XXX).
z Dial the desired phone number.
4.3.3Call Release
To release a call, press
END
( )
button. The
phone
( ) icon will be disappeared and the
wireless terminal will goes to an idle state.
4.3.4 Assign CO Line/CO Line Group
Available CO lines can be grouped and the accessible CO line groups can be assigned to a
station by Admin programming (For detail programming, refer to “CO LINE GROUPS” and “CO
LINE ACCESS” of “Digital Key Telephone System Programming Manual”). All available CO lines
are assigned to Group 01 by default.
Accessing a CO line is done in three ways as above; (9, 8+CO line group # or 88+CO line #)
and they are;
1) 9 (CO line Access Code): Connect an available CO line of the assigned CO line group to
the station. CO line selecting method is programmable by Admin programming.
2) 8 + CO line group #: Connect an available CO line of the CO line group. The CO line
group should be assigned to the station before by Admin programming. CO line selecting
method is programmable by Admin programming.
3) 88 + CO line #: Connect the CO line directly. The CO line should be allowed to the
station before by Admin programming.
