7.Key System Functions
49
3) Press
SPEED
( ) button shorter than 1second.
4) Dial speed bin number. (ipLDK-24/100/300/300E: 000~099)
(Only available speed bin is displayed on the LCD. And only one speed bin number is
displayed at every time using this function.)
5) Dial a phone number to be stored.
6) Press
PROGRAM
( ) button longer than 1 second.
7) Enter the dial name.
( Refer to “programming a name into display”)
8) Press
PROGRAM
( ) button longer than 1 second.
9) Press
END
( ) button.
10) You can store speed dials by repeating the above procedure.
STOP!
; If all speed bins are stored, speed bin number is displayed as ‘000’ on the LCD.
; You can newly edit speed bin that is already used.
7.5.2 Using Station Speed Bin Numbers
1) Press
TALK
( ) button.
2) Press
SPEED
( ) button shorter than 1 second.
3) Dial speed bin number (ipLDK-24/100/300/300E: 000~099).
7.5.3 Erasing Station Speed Bin Numbers
1) Press
TALK
( )
button.
2) Press
PROGRAM
( ) button longer than 1 second.
3) Press
SPEED
( ) button shorter than 1 second.
4) Dial speed number bin to be erased.
5) Press
PROGRAM
( ) button longer than 1 second.
(Confirmation tone will be heard)
6) Press
END
( ) button.
7.5.4 Storing System Speed Bin Numbers
You can use commonly speed dial numbers stored in the system.
1) Storing system speed dial number can be done only at the admin station.
2) Available CO line can be assigned at that time storing system speed dial number.
7.5.5 Using System Speed Numbers
1) Press
TALK
( ) button.
2) Press
SPEED
( ) button shorter than 1 second.
3) Dial speed bin number.
(ipLDK-24/100: 2000~3499, ipLDK-300: 2000~4999,ipLDK-300E: 2000~6999).
STOP!
; When a user makes a call to some exclusive subscribers or all CO lines are reserved, error
tone is heard.
; A speed dial number can be programmed as one that there is no limit about a long
distance call. (Refer to “Digital Key Telephone System Installation and Programming
Manual”)
