• Access point name — Enter the name for the
access point. The name is usually provided by
your service provider.
• User name — Enter your user name if required
by the service provider. User names are often
case-sensitive and provided by your service
provider.
• Prompt password — Select Yes to enter your
password each time you log into a server or No
to save the password in your device memory and
automate the login.
• Password — Enter your password if required by
the service provider. The password is often case-
sensitive and provided by the service provider.
• Authentication — Select Secure to send your
password always encrypted, or Normal to send
your password encrypted when possible.
• Homepage — Enter the web address of the page
you want to display as the home page when you
use this access point.
4. After defining the settings, select Options >
Advanced settings to define the advanced
settings or Back to save the settings and exit.
Advanced internet access
point settings for packet
data (GPRS)
Select Menu > Tools > Settings > Connection >
Access points.
After setting up a basic internet access point for packet
data (GPRS), select Options > Advanced settings,
and define the following advanced settings:
• Network type — Select IPv4 or IPv6 as the internet
protocol type. The internet protocol defines how
data is transferred to and from your device.
• Phone IP address — Enter the IP address of your
device. Select Automatic to have the network
provide the device IP address. This setting is shown
only if you select Network type > IPv4.
• DNS address — Select Primary DNS address and
Secondary DNS address and enter their IP
addresses, if required by your service provider.
Otherwise, the name server addresses are provided
automatically.
• Proxy server address — Enter the address of the
proxy server. Proxy servers are intermediate servers
used by some service providers between a browsing
service and its users. These servers may provide
additional security and speed up access to the
service.
Set up an access point for
WLAN manually
1. Select Menu > Tools > Settings >
Connection > Access points.
2. Select Options > New access point to create a
new access point, or select an existing access point
from the list and then Options > Duplicate access
point to use the access point as a basis for the new
one.
3. Define the following settings.
