Basics 17
SIM card
The SIM card contains your phone number, service details, and phonebook/message memory.
Your phone supports both 1.8V and 3 V SIM cards.
Some legacy SIM cards may not function with your phone. You should consult with your mobile
operator for a replacement SIM card. There may be fees for this service.
Inserting the SIM card
Remove the back cover. Refer to “Removing the back cover.”
If the battery is installed, remove the battery. Refer to “Removing the battery.”
Insert the SIM card with its gold contacts facing down and its cut-off corner facing out.
4. Push the SIM card all the way in.
Removing the SIM card
Remove the back cover. Refer to “Removing the back cover.”
If the battery is installed, remove the battery. Refer to “Removing the battery.”
Push the SIM card out from the back of the slot, and then slide the SIM card out.
Storage card
Store your pictures, music, and applications in the microSD card that is pre-installed on your
phone.
Inserting the storage card
Remove the back cover. Refer to “Removing the back cover.”
If the battery is installed, remove the battery. Refer to “Removing the battery.”
Insert the microSD card into the slot with its gold contacts facing down and push it in until
it clicks into place.
1.
2.
3.
1.
2.
3.
1.
2.
3.
