272 Appendix
A.1 Specifications
Processor TI’s OMAP™ 850 201 MHz
Operating System Windows Mobile® 6.1 Professional
Memory ROM : 256 MB
RAM : 128 MB
Note: Figures are the total ROM and RAM memory available for use and
storage. Since the memory is shared by the operating system, applications,
and data, the actual available memory is less than what is specified.
•
•
Dimensions 104.5 mm (L) X 59 mm (W) X 15.75 mm (T)
Weight 110 g (with battery)
Display 2.8-inch TFT-LCD touch-sensitive screen
Network Quad-band GSM/GPRS/EDGE:
850/900/1800/1900 MHz
(Band frequency is operator dependent.)
•
Device Control TouchFLO™
4-Way navigation control with Enter button
•
•
Connectivity Bluetooth® 2.0 with EDR
Wi-Fi® (IEEE 802.11 b/g)
HTC ExtUSB™ (11-pin mini-USB 2.0 and audio jack in one)
•
•
•
Audio Built-in microphone and speaker
Ring tone supported formats:
Supports eAAC+, AAC+, AAC, AMR-NB, AMR-WB, QCP, MIDI, MP3,
MPEG4-Audio, WMA, WAV formats
40 polyphonic and standard MIDI format 0 and 1 (SMF) / SP MIDI
•
•
Battery Rechargeable Lithium-ion battery
Capacity: 1100 mAh
Standy time: Up to 270 hours
Talk time: Up to 480 minutes
(The above are subject to network and phone usage.)
•
•
•
•
Expansion Slot microSD™ (SD 2.0 compatible)
AC Adapter Voltage range/frequency: 100 - 240V AC, 50/60 Hz
DC output: 5V and 1A
