Nokia N90-1 Cell Phone User Manual



Copyright
©
2005 Nokia. All rights reserved.
Tools
109
Packet data connections in GSM and UMTS
networks
When you use your phone in GSM and UMTS networks,
multiple data connections can be active at the same time
and access points can share a data connection. In the
UMTS network, data connections remain active during
voice calls. To check the active data connections, see
"Connection manager", p. 102.
The following indicators may be displayed below the signal
indicator, depending on which network you use:
GSM network, packet data is available in the network.
GSM network, packet data connection is active, data is
being transferred.
GSM network, multiple packet data connections are
active.
GSM network, packet data connection is on hold. (This
can happen during a voice call, for example.)
UMTS network, packet data is available in the network.
UMTS network, packet data connection is active, data is
being transferred.
UMTS network, multiple packet data connections are
active.
UMTS network, packet data connection is on hold.
Receive access point settings
You may receive access point settings in a text message
from a service provider, or you may have preset access
point settings in your phone. See "Data and settings", p. 70.
To create a new access point, press , and select Tools >
Settings > Connection > Access points.
An access point may be protected ( ) by your network
operator or service provider. Protected access points
cannot be edited or deleted.
Access points
Tip! See also "Receive MMS and e-mail settings",
p. 68, "E-mail", p. 76, and "Access the Web", p. 82.
Follow the instructions given to you by your service
provider.
Connection name—Give a descriptive name for the
connection.
Data bearer—Depending on what data connection you
select, only certain setting fields are available. Fill in all
fields marked with Must be defined or with a red asterisk.
Other fields can be left empty, unless you have been
instructed otherwise by your service provider.
To be able to use a data connection, the network service
provider must support this feature, and if necessary,
activate it for your SIM card.
