instructions on the screen. Or, open one of the access
point groups, select an access point marked with
, and
select Edit.
Follow the instructions from your service provider.
● Access point name — You obtain the access point
name from your service provider.
● User name — The user name may be needed to make
a data connection, and is usually provided by the
service provider.
● Prompt password — If you must enter the password
every time you log in to a server, or if you do not want
to save your password in the device, select Yes.
● Password — A password may be needed to make a
data connection and is usually provided by the service
provider.
● Authentication — Select Secure to always send your
password encrypted or Normal to send your password
encrypted when possible.
● Homepage — Depending on the access point you are
setting up, enter the web address or the address of the
multimedia messaging centre.
Select Options > Advanced settings to change the
following settings:
● Network type — Select the internet protocol type to
transfer data to and from your device. The other
settings depend on the selected network type.
● Phone IP address (for IPV4 only) — Enter the IP
address of your device.
● DNS addresses — Enter the IP addresses of the
primary and secondary DNS servers, if required by your
service provider. Contact your internet service provider
to obtain these addresses.
● Proxy server address — Enter the address of the
proxy server.
● Proxy port number — Enter the port number of the
proxy server.
WLAN internet access points
Press , and select Tools > Settings > Connection >
Destinations > New access point, and follow the
instructions on the screen. Or, open one of the access
point groups, select an access point marked with
, and
select Edit.
Follow the instructions from your WLAN service provider.
● WLAN network name — Select Enter manually or
Search for networks. If you select an existing
network, WLAN network mode and WLAN security
mode are determined by the settings of its access
point device.
● Network status — Define whether the network name
is displayed.
● WLAN network mode — Select Ad-hoc to create an
ad hoc network and to allow devices to send and
© 2008 Nokia. All rights reserved.148
