(See diagram 27A, 27B) The Air Cylinder/ Piston Assembly (D400) is composed
of eight basic parts:
The Cylinder Body (D401)
The Piston (D402)
The Piston Set Screw (D403)
The Connecting Rod (D405)
The Back Plate (D410)
The Back Plate Retaining Ring (D412)
The Bushing (D406)
The Bushing C-Clip (D409)
The Thumbscrew (D413)
There are six O rings associated with this assembly:
Inside Bushing O Ring (D407)
Outside Bushing O ring (D408)
(2) Piston O Rings (D404)
Connecting Rod O Ring (D602)
Back Plate O Ring (D410)
