3.2
MAINTENANCE | SERVICE
Mix CartridgeMix Cartridge
Mix CartridgeMix Cartridge
Mix Cartridge
ServiceService
ServiceService
Service
(D603 or Optional(D603 or Optional
(D603 or Optional(D603 or Optional
(D603 or Optional
Cartridge)Cartridge)
Cartridge)Cartridge)
Cartridge)
3.2.5
(See diagram 47A)
There are no user serviceable parts inside the Mix Cartridge (D603). Do not
pull the center rod out of the Mix Cartridge. Do not attempt to disassemble
the Mix Cartridge.
If the Mix Cartridge seizes, the rod in the center of the Mix Cartridge will not
move, and the F1000 will not operate.
If the F1000 will not move the center rod in the Mix Cartridge when the trigger
is pressed, check the following items:
1 | Make sure that the F1000 is connected to a compressed air source.
2 | Make sure that the Air Cylinder/ Piston Assembly (D400) is operating cor-
rectly. This Piston operates the Mix Cartridge, and if the Piston is stuck for any
reason, the F1000 will not move the rod in the Mix Cartridge. To determine if
the Air Cylinder/Piston Assembly is operating correctly, remove the Mix Car-
tridge as described in the next section, and trigger the F1000 with the Air
Cylinder/ Piston Assembly installed. If the Air Cylinder Assembly is working, but
the Mix Cartridge does not work when installed, the Mix Cartridge will have to
be replaced.
